YALE UNITY SLIM SMART LOCK 50/4P S

Yale Unity Slim Smart Lock

Introducing a keyless, secure, and user-friendly smart lock designed for all types of hinged doors. The Yale Unity Slim Smart Lock offers both keypad entry and seamless control through the Yale Home App on your smartphone. Installation is a breeze on slender to wide aluminium doors. Designed in New Zealand to withstand the harshest weather conditions, the Unity Slim Smart Lock uses the Induro 4-Point lift-to-lock system, which enhances security and provides improved door seal performance. This updated version of the Induro 4-Point lock is specifically designed for secure compatibility with the Unity Slim Smart Lock escutcheon.

Features

• Features 4 points of locking from the latch, deadbolt and two shootbolts (not included)
• The handing of the lockset is adjusted by reversing the orientation of the latch bolt
• 50mm backset
• 85mm pitch
• Preset 13mm throw on deadbolt
• Suitable for 35mm to 60mm door thicknesses
• Stainless steel forend plate
• Adjustable latch projection
• Latch wear insert included
• Lock rods and tips not included
• Includes packers and alternate strikes
• Designed for aluminium joinery suites
• When used with the correct strike the lock generates optimum seal compression to provide improved water and air seal performance, especially for large panel doors
• Polyester powdercoated finish on furniture
• New Zealand designed

Keyless Entry
Coming home has never been easier with the Unity Slim Smart Lock. Effortlessly unlock by using the keypad or use the Yale Home App to turn on the Auto-Unlock feature in your App so your door will unlock as you approach it.

Effortless locking
Simply lift the handle to activate multipoint locking, enhancing security and door sealing performance.

Built for New Zealands harshest weather
With multipoint locking for enhanced door sealing performance, a UV tested screen and an IP55 rating, the Unity Slim Smart Lock has been designed and tested to withstand New Zealands harshest weather.

Make more doors smart
The Unity Slim Smart Lock fits a range of hinged doors, from slender door profiles to grand entrances.

Door position sensor
With DoorSense you’ll know if your door is locked, unlocked or open.

Emergency Power Supply
Rest assured as both the lock and the Yale Home App will let you know when your batteries are low and need changing soon. However, in the case your lock batteries do run flat, all youll need is a USB-C cable and a phone or power bank to power your lock.

Total control via the Yale Home App

• Smartphone convenience: Lock and unlock your door with your smartphone
• Grant entry: Provide access to family, friends, and tradies with individual PIN codeswhether it’s a one-time use or scheduled entry for specific days and times
• Auto-Unlock: Enable the Auto-Unlock feature in the App to automatically unlock your door as you approach it
• Visitor tracking: Monitor who comes and goes with ease

Upgrade with the Yale Connect Plus Hub 2 for:

• Manage access to your home from anywhere
• Remote locking/unlocking
• Integrate with voice assistants and smart home ecosystems, Amazon Alexa and Google Home, for hands-free control

* Yale Connect Plus Hub 2 is required and sold separately

Specifications

• IP55 rating
• UV tested
• 4 x AA Alkaline batteries
• Operating temperature range -15C to 55C
• Operating humidity range 0% to 90%

Keypad Dimensions
Width: 37.5mm
Length: 287mm
Depth: 49mm

Kit Includes
Yale Unity Slim Smart Lock
Yale Unity Induro 4-Point mortice lock
Yale Unity Strike SS (contains magnet for DoorSense)
Yale Unity Magnet Housing (contains magnet for DoorSense)
Yale Unity 2mm Packer
Yale Unity 3mm Packer
Routing template
User guide and installation instructions
Screw pack
4 x AA Alkaline batteries

Finish
Black
