WAVESHARE OS08A10 8MP M12 USB Camera Module

1. Pixel: 8 million
2. Sensor chip: OS08A10
3. Interface type: USB 2.0
4. Camera:
– Sensor size: 1/1.8 inch
– Aperture (F): 1.6
– Focal length (EFL): 4.2mm
– Field of view (FOV): 68 degrees (D) / 60 degrees (H) / 35 degrees (V)
– Focus mode: fixed focus
– Aberration: less than -2.4%
– Infrared filter: 650nm filter
– Shutter mode: rolling shutter
5. Image:
– Supported formats: MJPG, YUY2
– Still picture resolution: 3840 x 2160
– MJPG: 25FPS 3840 x 2160, 25FPS 2560 x 1440, 25FPS 1920 x 1080, 60FPS 1280 x 960, 60FPS 1280 x 720, 60FPS 640 x 480
– YUY2: 1FPS 3840 x 2160, 1FPS 2592 x 1440, 1FPS 1920 x 1080, 15FPS 1280 x 720, 30FPS 640 x 480
6. Communication interface: SH1.0 5PIN USB
7. Operating voltage: 5V +/- 5%
8. Operating current: 220mA
9. Size: about 3.8 x 3.8 x 2.4cm

Features:
1. HD resolution, OS08A10 8 megapixels, far and near the scene are clear, high-definition images easily fixed
2. Excellent low-light performance, even in low-light environment can provide excellent image quality, in the dark environment still maintain a clear picture quality
3. USB 2.0 interface, driver-free, can be easily connected with all kinds of USB hosts
